Part / Product Specification and Notes
| Maximum Airflow (at zero Static Pressure) |
690CFM (1170m³/h) |
| Fan Blade Ø |
225mm (9") |
| Standard Features |
Waterproof motor, IP 68 |
|
Low noise |
|
Long life |
|
36 Months Guarantee |
| Operating Voltage |
24v (tested at:26v) |
| IP Rating |
IP68 |
| SPAL Type/Description |
VA07-BP12/LL-58A 10 FTBT |
|
/LL: Long life |
|
BT: Standard Connector |
|
10FT: 10 holes for blow-off water |
| Airflow Direction |
Suction |
| Mounting Bolt/Screw |
M5 bolt |
| Mounting Torque |
3(+1/-0) Nm |
| Certifications |
UNI EN ISO 9001:2008 |
|
ISO TS 16949 |
|
ISO 14001 |
For additional technical details / dimensions please refer to catalogue pages
